CP180L Robot
HIGH-SPEED PALLETIZING ROBOT
The CP series palletizing robots feature industry leading cycle times, a broad motion range, a space and energy saving ller, and easy-to-use palletizing software to program the robot’s operation. The robots drive the flexible automation of end-of-line and distribution processes in a wide range of industries, and support the highest production line efficiencies. WIth the lightest maximum payload capacity, the CP180L model's throughout is the highest of the CP series palletizing robots.
Payload 180 kg PalletizingCP180L Robot Overview:
Max. Reach 3,255 mmApplications:
CP180L Robot SPECIFICATIONS
| CP180L SPECIFICATIONS | |||
| Type | Articulated Robot | ||
|---|---|---|---|
| Degrees of Freedom (axes) | 4 | ||
| Payload (kg) | 160 | ||
| Max. Reach (mm) | 3,255 | ||
| Positional Repeatability (mm) ✽1 | ±0.5 | ||
| Motion Range (°) | Arm Rotation (JT1) | ±160 | |
| Arm Out-in (JT2) | +95 - −46 | ||
| Arm Up-down (JT3) | +15 - −110 | ||
| Wrist Swivel (JT4) | ±360 | ||
| Wrist Bend (JT5) | - | ||
| Max. Speed (°/s) | Arm Rotation (JT1) | 140 ✽2 | |
| Arm Out-in (JT2) | 125 ✽2 | ||
| Arm Up-down (JT3) | 130 ✽2 | ||
| Wrist Swivel (JT4) | 400 ✽2 | ||
| Moment of inertia (kg•㎡) | 50 ✽2 | ||
| Palletizing Capacity (cycle/hour) ✽3 | 2,050 ✽2 | ||
| Mass (kg) | 1,600 | ||
| Mounting | Floor | ||
| Installation Environment | Ambient Temperature (°C) | 0 - 45 | |
| Relative Humidity (%) | 35 - 85 (No dew, nor frost allowed) | ||
| Controller / Power Requirements (kVA) | E03 / 12 | ||
✽1: The figure conforms to ISO9283.
✽2: In case of 130 kg payload or smaller.
✽3: Motion pattern (400 mm up, 2,000 mm horizontal, 400 mm down in a to-and-fro motion)
