Payload 8kg Reach 832 mm 6 Axis High accuracy High Speed Assembly machine&Material handling robot
Features
High Speed, High accuracy, Large working envelope, High reliability & flexibility
| Max.MotionRange | Main Axes Wrist Axes | Swivel Horizontal Vertical R2 B(Bending) R1(Twisting) | ±170 ° +180 ° ~ -55 ° +213 ° ~ -66 ° ±190 ° ±135 ° ±360 ° |
| Max.Speed | Main Axes Wrist Axes | Swivel Horizontal Vertical R2 B(Bending) R1(Twisting) | 455 °/s 385 °/s 520 °/s 550 °/s 550 °/s 1000 °/s |
| AllowableTorque | Wrist Axes | R2 B(Bending) R1(Twisting) | 1.73 kgf·m 1.73 kgf·m 1.02 kgf·m |
